1994 50" Maxson MSE Fixed Bed Sheeter

50" wide Maxson MSE single knife sheeter

13” – 53” cut off range.

330 fpm

shafted unwind 60" diameter

with edge guide, trim blower, and lowering table

The MSE Sheeter is designed for operations that needs as few as 2000 sheets per order. Outfitted with an AC drive geared to 300 fpm (90 mpm), theMSE can also sheet up to four rolls simultaneously, offering the capacity to increase production when required.

The MSE Sheeter's solid revolver construction insures trouble free performance on a wide range of materials, cutting upto 0.024" thick (400 gsm) board. Quick and simple to set up by a single operator, lengths are preset to within 0.01" (0.1 mm). A digital sheet length monitor allows the size to be set.

Within its 6’ x 10’ (2 x 3 m) foot print,the MSE Sheeter can convert rolls up to57” (1450 mm) wide into lengths between 13”-52” (330-1320mm) long. The standard pile height is 43” (1100 mm) high. It can be outfitted with appropriate static eliminating equipment, slitter rig, and tag inserters.

Features

• Cutting up to 0.024" (400gsm) thick

• Pile height of 43" (1100mm)

• Converts rolls up to 57" (1450mm)wide

Benefits

• Quick and simple to set up • Set up by a single operator • Compact Foot Print

Specifications: Imperial / Metric

• CutOffRange:13"-52"/330-1320mm

• Available Knife Width: 53" / 1346 mm

• Maximum Knife Loading: 250lbs/330 sq. ft. / 425 gsm • Sheet Length Accuracy: +/- 0.120" / +/- 1.60 mm
